PRODUCT DESCRIPTION
MITSUBISHI FR-BU-H15K - Dynamic Braking Unit
This unit is a MITSUBISHI FREQROL series dynamic braking unit engineered for the management of regenerative energy in industrial motor control systems. It integrates with compatible MITSUBISHI variable frequency drives to dissipate excess energy through an external braking resistor, preventing DC bus overvoltage conditions during motor deceleration or braking operations. The FR-BU-H15K is designed for applications requiring controlled stopping or frequent load changes.
Technical Specifications:
SERIES/FAMILY: FREQROL (General series compatibility)
COMPONENT TYPE: Dynamic Braking Unit
ELECTRICAL SPECS:
COMPATIBLE INVERTER POWER: 15 kW
COMPATIBLE INVERTER VOLTAGE CLASS: 400VAC (3-Phase)
BRAKING RESISTOR COMPATIBILITY: Requires external braking resistor (resistance and power rating determined by application duty cycle and deceleration requirements)
BRAKING METHOD: Chopper control of DC bus voltage
MECHANICAL/PHYSICAL:
FORM FACTOR: Enclosed module
MOUNTING: Panel mount
INTERFACE/CONTROL:
CONNECTION: DC bus terminals for inverter interface, terminals for external braking resistor
CONTROL LOGIC: Internal voltage sensing and switching for braking activation
INDICATORS: Operational status LED
ENVIRONMENTAL/MOUNTING:
IP RATING: IP20
COOLING METHOD: Natural convection
MOUNTING STYLE: Vertical panel mount
COMPATIBILITY/APPLICATION:
COMPATIBLE INVERTER SERIES: MITSUBISHI FREQROL series variable frequency drives (e.g., FR-A800, FR-F800, FR-E700 series, dependent on specific model and voltage class)
TARGET APPLICATIONS: Conveyor systems, centrifuges, hoists, machine tools, and other industrial machinery requiring controlled deceleration of high-inertia loads.
