MITSUBISHI - HK-KT23G5 1/45 - Motors
HK-KT23G5 1/45 MITSUBISHI

MITSUBISHI
Condition
 New Sealed

The product is an item that has never been used and was obtained through a surplus supplier.

  • Never used in a production environment, but it may have been powered on for testing
  • No visible signs of handling, use, or damage
  • Includes the original packaging, if applicable
  • May or may not have the original manufacturer's seal on the box. The original manufacturer's warranty may not be applicable.
  • Includes all hardware and accessories present in the factory new version of the product
  • May or may not include the instructions present in the factory new version of the product
  • The product may have older date or serial codes compared to those available directly from the manufacturer or authorized retailers
  • Products may vary by country of origin and by language used on the packaging
  • The product packaging may show signs of shelf wear
 New BAS

The product is an item that has never been used and has been sourced from an excess supplier.

  • Never used in a production environment, but it may have been powered on for testing.
  • The product may show slight superficial signs of handling, but no signs of use or damage.
  • It may or may not have the original packaging. If the original packaging is not available, the product will generally be packaged in aftermarket packaging or branded BAS.
  • Hardware, accessories, or instructions present in the factory new version of the product may be missing. The manufacturer's warranty may not apply.
  • The product may have older date or serial codes compared to those available directly from the manufacturer or authorized retailers.
  • Products may vary by country of origin and by language used on the packaging.
  • The packaging may contain markings not from the original manufacturer (OEM).
 New Fast Delivery

The product is an item that has never been used and was obtained through a surplus supplier.

  • Never used in a production environment, but it may have been powered on for testing
  • No visible signs of handling, use, or damage
  • Includes the original packaging, if applicable
  • May or may not have the original manufacturer's seal on the box. The original manufacturer's warranty may not be applicable.
  • Includes all hardware and accessories present in the factory new version of the product
  • May or may not include the instructions present in the factory new version of the product
  • The product may have older date or serial codes compared to those available directly from the manufacturer or authorized retailers
  • Products may vary by country of origin and by language used on the packaging
  • The product packaging may show signs of shelf wear
  • Faster shipping
Request information for HK-KT23G5 1/45 MITSUBISHI

PRODUCT DESCRIPTION

MITSUBISHI HK-KT23G5 1/45 - AC Synchronous Servo Motor

The MITSUBISHI HK-KT23G5 1/45 is a compact AC synchronous servo motor from the MELSERVO-J4 series, engineered for precise motion control in industrial automation applications. It integrates a high-resolution absolute encoder for accurate position feedback, making it suitable for demanding tasks in robotics, CNC machinery, material handling, and general industrial motion systems requiring dynamic response and repeatability.

Technical Specifications:

  • SERIES/FAMILY: MELSERVO-J4 Series
  • COMPONENT TYPE: AC Synchronous Servo Motor
  • ELECTRICAL SPECS:
    • POWER RATING: 200W (0.2kW)
    • NOMINAL VOLTAGE: 200VAC Class (requires compatible servo amplifier)
    • NOMINAL CURRENT: Approximately 1.5A RMS (varies with load and amplifier)
    • PHASE: Three-phase (driven by inverter)
    • FREQUENCY: 0-360 Hz (dependent on speed and pole count)
  • MECHANICAL/PHYSICAL:
    • NOMINAL TORQUE: 0.64 Nm
    • MAXIMUM TORQUE: 1.91 Nm
    • NOMINAL SPEED: 3000 RPM
    • MAXIMUM SPEED: 6000 RPM
    • SHAFT TYPE: Straight shaft with keyway (typical for this series, specific variant may differ)
    • FRAME SIZE: Compact flange mount (e.g., 60mm square flange, specific dimensions vary by model)
    • INERTIA: Low to Medium Inertia
  • INTERFACE/CONTROL:
    • FEEDBACK DEVICE: 22-bit Absolute Encoder
    • ENCODER RESOLUTION: 4,194,304 pulses/revolution
    • COMMUNICATION PROTOCOL (SYSTEM LEVEL): Compatible with MELSERVO-J4 amplifiers supporting SSCNET/H, EtherCAT, PROFINET, CC-Link IE Field Basic, and other industrial networks.
  • ENVIRONMENTAL/MOUNTING:
    • IP RATING: IP65 (shaft end), IP67 (body, typical for standard models)
    • COOLING METHOD: Natural convection
    • MOUNTING STYLE: Flange mount
  • COMPATIBILITY/APPLICATION:
    • COMPATIBLE AMPLIFIER: MITSUBISHI MELSERVO-J4 Series Servo Amplifiers (e.g., MR-J4-20A, MR-J4-20B)
    • TARGET APPLICATIONS: Robotics, CNC machine tools, packaging machinery, material handling systems, semiconductor manufacturing equipment, general industrial automation requiring high-precision motion.

1 year warranty

HS CODE

85015100

DELIVERY TIME

10 working days

Price excluding VAT

Return conditions

You can return the purchased product according to the Terms and Conditions

Warranty

Automantion Service Srl is NOT an official distributor of the manufacturer. The manufacturer's warranty does not apply. Terms and conditions
