Request information for MDS-E-V2-20 MITSUBISHI

PRODUCT DESCRIPTION

MITSUBISHI MDS-E-V2-20 - Spindle Drive Unit

The MITSUBISHI MDS-E-V2-20 is a high-performance spindle drive unit from the MITSUBISHI MDS-E-V2 series, engineered for precise control of AC spindle motors in industrial machine tools. This unit integrates advanced vector control technology to deliver dynamic speed and torque regulation, making it suitable for demanding CNC applications such as milling machines, lathes, and grinding centers requiring high-accuracy machining operations. It functions as a critical component within integrated MITSUBISHI CNC systems, ensuring synchronized motion and power delivery.

Technical Specifications:

  • SERIES/FAMILY: MITSUBISHI MDS-E-V2 Series
  • COMPONENT TYPE: Spindle Drive Unit
  • ELECTRICAL SPECS:
    • NOMINAL INPUT VOLTAGE: 200-230VAC
    • PHASE: 3-Phase
    • INPUT FREQUENCY: 50/60 Hz
    • RATED OUTPUT CURRENT: 20A
    • RATED OUTPUT POWER: Approximately 6.9 kW (at 200VAC)
  • MECHANICAL/PHYSICAL:
    • FUNCTION: Controls AC spindle motors for speed and torque
    • FORM FACTOR: Modular, cabinet-mount
    • COOLING: Forced air cooling (integrated fan)
  • INTERFACE/CONTROL:
    • CONTROL METHOD: High-performance vector control
    • COMMUNICATION: Proprietary high-speed serial interface for MITSUBISHI CNC systems
    • FEEDBACK: Encoder input for spindle motor position and speed feedback
  • ENVIRONMENTAL/MOUNTING:
    • IP RATING: IP20 (for cabinet installation)
    • MOUNTING STYLE: Vertical cabinet mounting
    • OPERATING TEMPERATURE: 0 to 55 degrees C
  • COMPATIBILITY/APPLICATION:
    • COMPATIBILITY: MITSUBISHI CNC systems (e.g., M70, M80 series)
    • APPLICATION: CNC machine tools, milling machines, lathes, grinding machines, precision machining centers

1 year warranty
