PRODUCT DESCRIPTION
SCHNEIDER ELECTRIC 47074 - TeSys D Contactor
The SCHNEIDER ELECTRIC 47074 is a TeSys D series 3-pole contactor, specifically model LC1D09M7, designed for switching power circuits up to 9A AC-3. It integrates an electromagnetic coil for control and is suitable for motor control, resistive load switching, and general industrial automation applications within control panels and machinery. This component provides reliable switching functionality for industrial electrical systems.
Technical Specifications:
- SERIES/FAMILY: TeSys D
- COMPONENT TYPE: Contactor
- ELECTRICAL SPECS:
- NOMINAL OPERATIONAL CURRENT (AC-3): 9A at <= 60 °C (220-690V)
- NOMINAL OPERATIONAL CURRENT (AC-1): 25A at <= 60 °C (<= 690V)
- COIL VOLTAGE: 220VAC 50/60Hz
- NUMBER OF POLES: 3P (Power Circuit)
- RATED MOTOR POWER (AC-3): 2.2kW at 220-230V AC 50/60Hz
- RATED INSULATION VOLTAGE (Ui): 690V (Power Circuit), 600V (CSA), 690V (UL)
- RATED IMPULSE WITHSTAND VOLTAGE (Uimp): 6kV
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Block Contactor
- AUXILIARY CONTACTS: 1 NO (Normally Open) + 1 NC (Normally Closed)
- INTERFACE/CONTROL:
- CONTROL CIRCUIT TYPE: AC 50/60Hz
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (Front Face)
- OPERATING TEMPERATURE: -5 to 60 °C
- MOUNTING STYLE: 35mm DIN Rail or Screw Fixing
- COMPATIBILITY/APPLICATION: Motor control circuits, resistive load switching, industrial automation panels, HVAC systems, general power switching applications.
