PRODUCT DESCRIPTION
WEIDMULLER 1739650000 - u-remote IP67 PROFINET IO-Link Master Module
This is a decentralized PROFINET IO-Link Master module from the u-remote IP67 series, designed for robust field-level automation in harsh industrial environments. It facilitates the integration of intelligent IO-Link sensors and actuators into PROFINET control architectures, enabling comprehensive diagnostics and parameterization directly from the PLC.
Technical Specifications:
- SERIES/FAMILY: u-remote IP67
- COMPONENT TYPE: PROFINET IO-Link Master Module
- ELECTRICAL SPECS: 24VDC Nominal Input Voltage, Max. 10A Total Current, 200mA Output Current per IO-Link Port
- INTERFACE/CONTROL: PROFINET IO (RT/IRT Capable) Fieldbus Protocol, 4 x IO-Link Master Ports (Class A/B Configurable), M12 Connectors for Power, PROFINET, and IO-Link
- DATA RATE: IO-Link COM2 (38.4 kbaud) and COM3 (230.4 kbaud) Support
- ENVIRONMENTAL/MOUNTING: IP67 Protection Rating, -20 °C to +60 °C Operating Temperature, Direct Machine Mounting via Screws, Passive Convection Cooling
- COMPATIBILITY/APPLICATION: Integration with PROFINET-enabled PLCs and Control Systems, Decentralized Automation, Machine Building, Process Automation, Material Handling, Robotics, Connecting Intelligent IO-Link Devices
