DESCRIPCIÓN DEL PRODUCTO
SCHNEIDER ELECTRIC C080N360FM - AC Synchronous Servo Motor
This SCHNEIDER ELECTRIC C080N360FM is an AC synchronous servo motor designed for precise motion control in industrial automation applications. It integrates an 80mm flange frame, a nominal speed of 3600 RPM, and an advanced multi-turn absolute encoder feedback system, making it suitable for dynamic positioning tasks requiring high accuracy and repeatability. The motor is engineered for seamless integration with Lexium series servo drives, targeting applications such as CNC machinery, robotics, material handling systems, and automated assembly lines.
Technical Specifications:
- SERIES/FAMILY: Lexium 32 Series (Inferred)
- COMPONENT TYPE: AC Synchronous Servo Motor
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 400VAC
- PHASE: 3-Phase
- NOMINAL POWER: 1.1 kW
- NOMINAL CURRENT: 2.0 A
- NOMINAL FREQUENCY: 50/60 Hz (Drive Dependent)
- MECHANICAL/PHYSICAL:
- NOMINAL TORQUE: 2.9 Nm
- MAXIMUM TORQUE: 8.7 Nm
- NOMINAL SPEED: 3600 RPM
- MAXIMUM SPEED: 5000 RPM
- FRAME SIZE: 80mm x 80mm Flange
- SHAFT TYPE: Smooth with Keyway
- INERTIA: Medium
- BRAKE: Integrated Holding Brake
- INTERFACE/CONTROL:
- FEEDBACK: Multi-turn Absolute Encoder
- RESOLUTION: High Resolution Digital Encoder (e.g., 23-bit)
- COMMUNICATION: Digital Feedback Link (e.g., Hiperface DSL compatible)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (Motor Body), IP67 (Shaft Seal)
- COOLING METHOD: Natural Convection
- MOUNTING STYLE: Flange Mount (IEC Standard)
- COMPATIBILITY/APPLICATION:
- COMPATIBILITY: SCHNEIDER ELECTRIC Lexium 32 Servo Drives
- APPLICATION: CNC Machines, Robotics, Packaging Equipment, Material Handling, Automated Assembly
