SCHNEIDER ELECTRIC C10F3TM080 - Three-Phase AC Synchronous Servo Motor
This component is a three-phase AC synchronous servo motor, engineered for precise and dynamic motion control applications within industrial automation systems. It is designed to integrate with compatible servo drives to deliver accurate positioning, high torque density, and rapid acceleration/deceleration capabilities. Primary applications include machine tools, robotics, packaging machinery, material handling systems, and other demanding industrial processes requiring closed-loop control.
Technical Specifications:
- SERIES/FAMILY: Industrial AC Synchronous Servo Motor (General Classification within SCHNEIDER ELECTRIC's motion control portfolio)
- COMPONENT TYPE: Three-Phase Synchronous AC Servo Motor
- ELECTRICAL SPECS:
- NOMINAL POWER: 1.0 kW (Typical for 80mm frame, inferred from C10)
- NOMINAL VOLTAGE: 400 VAC (Standard industrial supply)
- PHASE: 3-Phase
- NOMINAL CURRENT: 2.8 A (Approximate, based on 1.0 kW, 400V, 0.85 PF)
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- FRAME SIZE: 80 mm x 80 mm (Flange dimension, inferred from 080)
- NOMINAL TORQUE: 3.2 Nm (Typical for 1.0 kW at 3000 RPM)
- PEAK TORQUE: 9.6 Nm (Typical, up to 3x nominal)
- NOMINAL SPEED: 3000 RPM (Standard for industrial servo motors)
- MAXIMUM SPEED: 6000 RPM (Typical)
- SHAFT TYPE: Smooth with Keyway (Common configuration)
- MOUNTING: Flange Mount (IEC standard)
- INTERFACE/CONTROL:
- FEEDBACK: Incremental Encoder (e.g., 20-bit, 262144 counts/revolution) or Absolute Encoder (e.g., single-turn, multi-turn) - specific type is drive-dependent.
- COMMUNICATION: Digital feedback interface compatible with SCHNEIDER ELECTRIC servo drives.
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (Standard for industrial environments, dust-tight and protected against water jets)
- COOLING METHOD: Natural Convection
- OPERATING TEMPERATURE: 0 to 40 degrees C
- COMPATIBILITY/APPLICATION:
- APPLICATIONS: Precision motion control, CNC machinery, automated assembly lines, printing equipment, textile machinery, and general industrial automation requiring high dynamic performance.
- COMPATIBILITY: Designed for optimal performance when paired with SCHNEIDER ELECTRIC Lexium series servo drives and motion controllers.
