DESCRIPCIÓN DEL PRODUCTO
SCHNEIDER ELECTRIC C10H3MA050 - AC Synchronous Servo Motor
The SCHNEIDER ELECTRIC C10H3MA050 is an AC synchronous servo motor belonging to the Lexium 10 series, designed for integration into industrial motion control systems. This motor provides precise speed and position control, operating in conjunction with Lexium 10 servo drives. Its compact form factor and robust construction make it suitable for applications such as material handling, packaging equipment, and automated assembly lines requiring dynamic and accurate axis control.
Technical Specifications:
- SERIES/FAMILY: Lexium 10
- COMPONENT TYPE: AC Synchronous Servo Motor
- ELECTRICAL SPECS:
- NOMINAL POWER: 0.5 kW (500 W)
- NOMINAL VOLTAGE: 230 VAC (typical operating voltage for this power class)
- MOTOR PHASE: Three-phase winding
- MECHANICAL/PHYSICAL:
- NOMINAL TORQUE: Approximately 1.6 Nm (continuous stall torque)
- MAXIMUM SPEED: 3000 RPM (nominal operating speed)
- SHAFT TYPE: Keyed smooth shaft
- FORM FACTOR: Flange mounted, compact design
- INTERFACE/CONTROL:
- FEEDBACK: Integrated incremental encoder (e.g., 2048 ppr) or absolute encoder (e.g., 17-bit) options, connected via dedicated motor cable to the servo drive.
- CONNECTION: Industrial power and feedback connectors.
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (motor body), IP41 (shaft end)
- COOLING METHOD: Natural convection
- MOUNTING STYLE: Flange mount
- COMPATIBILITY/APPLICATION:
- COMPATIBLE DRIVES: Schneider Electric Lexium 10 Servo Drives
- TARGET APPLICATIONS: Packaging machinery, material handling systems, small CNC axes, automated assembly equipment, general industrial automation.
