DESCRIPCIÓN DEL PRODUCTO
SCHNEIDER ELECTRIC XA2AT42 - Latching Flush Pushbutton Operator
This component is a Harmony XA2 series 22mm plastic pushbutton operator engineered for industrial control panel integration. It features a latching, flush-mounted red actuator, providing persistent manual state control for machinery and processes. The operator is designed for compatibility with Harmony XA2 contact blocks, enabling robust and reliable human-machine interface functionality in diverse industrial automation applications.
Technical Specifications:
- SERIES/FAMILY: Harmony XA2
- COMPONENT TYPE: Pushbutton Operator, Latching, Flush Mount
- ELECTRICAL SPECS: Designed for use with separately ordered contact blocks typical ratings for compatible blocks include Rated Insulation Voltage (Ui) 600V, Rated Impulse Withstand Voltage (Uimp) 6kV, and operational currents conforming to AC-15 (e.g., 3A @ 240V) and DC-13 (e.g., 0.27A @ 250V) standards.
- MECHANICAL/PHYSICAL: Actuator Type: Flush, Latching Actuator Color: Red Mounting Diameter: 22mm Bezel Material: Plastic Mechanical Durability: 1,000,000 cycles.
- INTERFACE/CONTROL: Manual actuation provides mechanical interface for electrical contact blocks (not included).
- ENVIRONMENTAL/MOUNTING: IP RATING: IP65 (front face) Operating Temperature: -25°C to +70°C Storage Temperature: -40°C to +70°C Mounting Style: Panel mount, 22mm cut-out.
- COMPATIBILITY/APPLICATION: Industrial control panels, machine interfaces, process control systems, general purpose ON/OFF or mode selection in automated equipment.
