SCHNEIDER ELECTRIC 18621 - Modicon M221 Compact Logic Controller
This is a Modicon M221 Compact Logic Controller, specifically the TM221C16R model. It is engineered for discrete control applications requiring integrated I/O and communication capabilities, serving as a foundational component in small to medium-sized automation systems, including material handling, packaging machinery, and HVAC control. The unit provides deterministic control logic execution and supports standard industrial communication protocols for system integration.
Technical Specifications:
- SERIES/FAMILY: Modicon M221
- COMPONENT TYPE: Compact Logic Controller (PLC)
- ELECTRICAL SPECS:
- NOMINAL SUPPLY VOLTAGE: 100-240VAC
- POWER CONSUMPTION: 25 VA
- DISCRETE INPUT VOLTAGE: 24VDC
- DISCRETE INPUT CURRENT: 7 mA
- DISCRETE OUTPUT VOLTAGE: 240VAC / 30VDC
- DISCRETE OUTPUT CURRENT: 2A (per relay output)
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Compact
- MOUNTING: DIN Rail
- INTERFACE/CONTROL:
- DIGITAL INPUTS: 9 (24VDC, sink/source)
- DIGITAL OUTPUTS: 7 (Relay type)
- COMMUNICATION PORTS: 1x Ethernet (RJ45), 1x Serial (RS232/RS485)
- PROGRAMMING LANGUAGE: IEC 61131-3 (SoMachine Basic)
- PROCESSOR: ARM Cortex-A8
- PROGRAM MEMORY: 20 MB
- DATA MEMORY: 20 MB
- REAL-TIME CLOCK: Integrated
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20
- OPERATING TEMPERATURE: 0 to 55 degrees C
- COOLING METHOD: Natural convection
- COMPATIBILITY/APPLICATION: Small to medium-scale industrial automation, standalone machines, material handling, packaging, pumping, HVAC systems, and general machine control.
