SCHNEIDER ELECTRIC 18813 - 3-Pole AC Contactor
This device is a TeSys D series 3-pole AC contactor, designated LC1D09M7, engineered for robust motor control and resistive load switching in industrial automation systems. It integrates a 220VAC 50/60Hz control coil and is suitable for applications requiring reliable power switching in control panels, HVAC systems, and material handling equipment. The contactor provides essential switching functionality for AC-3 motor loads up to 9A and AC-1 resistive loads up to 25A.
Technical Specifications:
- SERIES/FAMILY: TeSys D
- COMPONENT TYPE: 3-Pole AC Contactor
- ELECTRICAL SPECS:
- RATED OPERATIONAL CURRENT (AC-3): 9A at <= 440V
- RATED OPERATIONAL CURRENT (AC-1): 25A at <= 690V
- MOTOR POWER (AC-3): 2.2 kW at 220-230V 4 kW at 380-400V 5.5 kW at 500V 5.5 kW at 660-690V
- CONTROL CIRCUIT VOLTAGE: 220VAC 50/60Hz
- NUMBER OF POLES: 3P
- AUXILIARY CONTACTS: 1 Normally Open (NO) + 1 Normally Closed (NC)
- RATED INSULATION VOLTAGE: 690V (Power Circuit)
- RATED IMPULSE WITHSTAND VOLTAGE: 6kV
- MECHANICAL/PHYSICAL:
- MOUNTING: 35mm DIN Rail or Screw Fixing
- TERMINALS: Screw Clamp
- INTERFACE/CONTROL:
- CONTROL CIRCUIT TYPE: AC 50/60 Hz
- COIL CONSUMPTION (INRUSH): 70 VA at 20 °C
- COIL CONSUMPTION (HOLD-IN): 7.5 VA at 20 °C
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (Front Face)
- OPERATING TEMPERATURE: -5 to 60 °C
- COOLING METHOD: Natural Convection
- COMPATIBILITY/APPLICATION: Motor control circuits, resistive load switching, industrial control panels, HVAC systems, pumping applications, conveying systems.
