OPIS PRODUKTU
SCHNEIDER ELECTRIC 18864 - Industrial Servo Drive
This component represents a high-performance industrial servo drive from the SCHNEIDER ELECTRIC Lexium 32 series, engineered for precise motion control in demanding automation applications. It integrates advanced control algorithms for synchronous and asynchronous motors, facilitating accurate position, speed, and torque regulation. Designed for integration into complex machinery, it supports applications such as robotics, CNC machines, packaging lines, and material handling systems requiring dynamic and repeatable motion.
Technical Specifications:
- SERIES/FAMILY: Lexium 32
- COMPONENT TYPE: Servo Drive
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 200-240VAC (Single-phase/Three-phase) or 380-480VAC (Three-phase)
- POWER RANGE: 0.37 kW to 7 kW (model dependent)
- NOMINAL CURRENT: 2.6A to 20A (model dependent)
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Compact book-style module for cabinet mounting
- COOLING: Natural convection or forced air (integrated fan for higher power models)
- INTERFACE/CONTROL:
- COMMUNICATION PROTOCOLS: CANopen, Modbus TCP, EtherCAT, PROFINET, Sercos III (module dependent)
- FEEDBACK INTERFACE: Resolver, Incremental Encoder (TTL/HTL), Absolute Encoder (Hiperface, EnDat 2.1/2.2, SSI)
- FEEDBACK RESOLUTION SUPPORT: Capable of processing high-resolution feedback for precise motor control
- DIGITAL I/O: Configurable digital inputs and outputs for control and status
- ANALOG I/O: Configurable analog inputs and outputs
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (for cabinet mounting)
- OPERATING TEMPERATURE: 0 to 50 degrees Celsius
- MOUNTING STYLE: Vertical panel mounting
- COMPATIBILITY/APPLICATION:
- MOTOR COMPATIBILITY: SCHNEIDER ELECTRIC BMH, BSH, SH, and other compatible synchronous/asynchronous servo motors
- TARGET APPLICATIONS: Robotics, CNC machining, printing, packaging, material handling, textile machinery, general industrial automation requiring dynamic and repeatable motion profiles
