DESCRIZIONE PRODOTTO
SCHNEIDER ELECTRIC 18269 - Modicon M221 Logic Controller
The SCHNEIDER ELECTRIC 18269 is a Modicon M221 Logic Controller, specifically configured with 24 discrete I/O points and integrated Ethernet connectivity. This programmable logic controller provides deterministic control for compact industrial machinery, facilitating sequential operations and data exchange via standard industrial protocols. It is engineered for applications in small to medium-scale automation, including material handling, packaging, and specialized machine control.
Technical Specifications:
- SERIES/FAMILY: Modicon M221
- COMPONENT TYPE: Logic Controller (PLC)
- ELECTRICAL SPECS:
- INPUT VOLTAGE: 24 VDC
- DISCRETE INPUTS: 14 (8 fast inputs)
- DISCRETE OUTPUTS: 10 (Transistor NPN type)
- OUTPUT CURRENT: 0.5 A per output
- POWER CONSUMPTION: 20.4 W
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Compact DIN rail mountable module
- INTEGRATED PORTS: 1 x Ethernet, 1 x USB (programming), 1 x Serial (RS232/RS485 configurable)
- INTERFACE/CONTROL:
- COMMUNICATION PROTOCOLS: Ethernet (Modbus TCP/IP, EtherNet/IP), Serial (Modbus RTU/ASCII)
- PROGRAMMING LANGUAGE: IEC 61131-3 (Ladder Diagram, Function Block Diagram, Structured Text, Instruction List, Sequential Function Chart)
- FAST I/O CAPABILITY: High-speed counting, pulse generation, PWM
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20
- COOLING METHOD: Natural convection
- MOUNTING STYLE: DIN rail
- OPERATING TEMPERATURE: 0 to 55 °C
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Small to medium-scale automated machines, material handling, packaging, pumping, HVAC, textile machinery
- PROGRAMMING SOFTWARE: EcoStruxure Machine Expert - Basic
