SCHNEIDER ELECTRIC 18667 - Miniature Circuit Breaker
The SCHNEIDER ELECTRIC 18667 is a single-pole Miniature Circuit Breaker (MCB) from the Acti9 iC60N series, engineered for robust overcurrent and short-circuit protection in industrial and commercial electrical distribution systems. This thermal-magnetic device ensures reliable circuit isolation and fault interruption, critical for safeguarding equipment and personnel in panel boards, machinery control circuits, and general electrical installations.
Technical Specifications:
- SERIES/FAMILY: Acti9 iC60N
- COMPONENT TYPE: Miniature Circuit Breaker (MCB)
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 230V AC (Phase-to-Neutral)
- NOMINAL CURRENT: 16A
- POLES: 1P (Single Pole)
- TRIPPING CURVE: C Curve (Instantaneous trip between 5 and 10 times In)
- BREAKING CAPACITY: 6 kA at 230V AC (IEC/EN 60898-1)
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- MOUNTING: DIN Rail (35mm)
- MODULE WIDTH: 18mm (1 module)
- TERMINAL CAPACITY: Tunnel type terminals, up to 25 mm² (flexible), 35 mm² (rigid)
- INTERFACE/CONTROL:
- OPERATION: Manual toggle switch (ON/OFF)
- INDICATION: Mechanical trip indicator
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (terminals), IP40 (front face in enclosure)
- OPERATING TEMPERATURE: -35°C to +70°C
- STORAGE TEMPERATURE: -40°C to +85°C
- POLLUTION DEGREE: 3
- COMPATIBILITY/APPLICATION:
- APPLICATION: Protection of circuits against overloads and short-circuits in industrial, commercial, and residential electrical installations.
- STANDARDS: Compliant with IEC/EN 60898-1 and IEC/EN 60947-2.
