DESCRIZIONE PRODOTTO
SCHNEIDER ELECTRIC 18726 - Modicon M241 Logic Controller
The SCHNEIDER ELECTRIC 18726 is a Modicon M241 Logic Controller, engineered for precise control and automation of industrial machinery. This compact programmable logic controller integrates embedded Ethernet and serial communication capabilities, providing robust control for applications requiring deterministic performance and network connectivity. It is designed for use in small to medium-sized automation systems, including material handling, packaging, pumping, and HVAC systems.
Technical Specifications:
- SERIES/FAMILY: Modicon M241
- COMPONENT TYPE: Logic Controller (PLC)
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24VDC
- POWER CONSUMPTION: 30W (typical, including I/O)
- INPUT TYPE: Digital (14 inputs, 24VDC)
- OUTPUT TYPE: Digital (10 transistor outputs, 24VDC, 0.5A per output)
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Compact, DIN rail mountable
- DIMENSIONS: 150 mm (W) x 90 mm (H) x 95 mm (D) (typical for 24 I/O model)
- WEIGHT: 0.5 kg (typical)
- INTERFACE/CONTROL:
- COMMUNICATION PROTOCOLS: Ethernet (Modbus TCP/IP, EtherNet/IP), Serial (Modbus RTU, ASCII via RS232/RS485)
- PROGRAMMING LANGUAGE: IEC 61131-3 (Ladder Diagram, Function Block Diagram, Structured Text, Instruction List, Sequential Function Chart)
- PROGRAMMING SOFTWARE: EcoStruxure Machine Expert Basic (formerly SoMachine Basic)
- EMBEDDED PORTS: 1x Ethernet, 2x Serial (RS232/RS485)
- EXPANSION: Supports Modicon TM3 expansion modules
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20
- OPERATING TEMPERATURE: 0 to 55 degrees Celsius
- MOUNTING STYLE: DIN rail
- COOLING METHOD: Natural convection
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Small to medium-sized industrial machines, standalone equipment, distributed control systems
- SPECIFIC MACHINE TYPES: Packaging machines, material handling systems, pumping stations, HVAC units, textile machinery, conveying systems
