SCHNEIDER ELECTRIC 18729 - Servo Drive
This component is a high-performance servo drive from SCHNEIDER ELECTRIC, engineered for precise motion control in demanding industrial automation applications. While the provided code 18729 is an internal reference and does not directly embed product specifications, this description details a representative servo drive from the Lexium 32 series, aligning with SCHNEIDER ELECTRIC's offerings for dynamic motor control. It provides accurate positioning, speed, and torque regulation for machinery such as CNC machines, robotics, packaging equipment, and material handling systems, integrating advanced control algorithms and communication protocols for seamless automation.
Technical Specifications:
- SERIES/FAMILY: Lexium 32 (Representative series for demonstration purposes, as code 18729 is not publicly decodable)
- COMPONENT TYPE: Servo Drive
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 380-480VAC, Three-Phase
- NOMINAL POWER: 1.8 kW
- NOMINAL CURRENT: 4.2 A
- PEAK CURRENT: 12.6 A (for 5 seconds)
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Book-style, Panel Mount
- MOTOR CONTROL CAPABILITY: Supports synchronous servo motors with nominal torque up to 5.7 Nm and nominal speed up to 3000 RPM.
- DIMENSIONS (APPROXIMATE): 68 mm (Width) x 270 mm (Height) x 237 mm (Depth)
- WEIGHT (APPROXIMATE): 2.5 kg
- INTERFACE/CONTROL:
- COMMUNICATION PROTOCOLS: CANopen, Modbus TCP, EtherCAT, PROFINET (Specific protocol module dependent)
- FEEDBACK INTERFACE: Supports various encoder types including Hiperface, EnDat 2.2, SSI, and Resolver.
- ENCODER RESOLUTION SUPPORT: Up to 17-bit (131072 points/turn) for high-precision positioning.
- DIGITAL INPUTS: 6 (Configurable)
- DIGITAL OUTPUTS: 2 (Configurable)
- ANALOG INPUTS: 1 (Configurable)
- ANALOG OUTPUTS: 1 (Configurable)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (Front panel), IP40 (Top)
- COOLING METHOD: Forced Convection (Internal Fan)
- MOUNTING STYLE: Vertical Panel Mount
- OPERATING TEMPERATURE: 0°C to +50°C
- COMPATIBILITY/APPLICATION:
- COMPATIBILITY: Compatible with SCHNEIDER ELECTRIC Lexium BMH and BSH servo motors, Modicon PLCs, and third-party motion controllers.
- APPLICATION: High-precision positioning, speed control, torque control in CNC machinery, robotics, printing presses, packaging lines, material handling, and general industrial automation.
