SCHNEIDER ELECTRIC 31298 - Acti 9 Vigi iC60 Earth Leakage Add-on Block
This SCHNEIDER ELECTRIC Acti 9 Vigi iC60 earth leakage add-on block, identified by code 31298, provides residual current protection for electrical installations. Designed for seamless integration with Acti 9 iC60 miniature circuit breakers, it detects and interrupts earth fault currents to mitigate risks of electric shock and fire. This device is critical for enhancing safety and compliance in industrial, commercial, and infrastructure power distribution systems.
Technical Specifications:
- SERIES/FAMILY: Acti 9 Vigi iC60
- COMPONENT TYPE: Earth Leakage Add-on Block (Residual Current Device - RCD)
- ELECTRICAL SPECS:
- NOMINAL CURRENT (In): 63A
- POLES: 4P
- EARTH LEAKAGE SENSITIVITY: 30mA
- EARTH LEAKAGE PROTECTION TYPE: AC (detects sinusoidal AC residual currents)
- NOMINAL OPERATIONAL VOLTAGE (Ue): 230/400 VAC (dependent on associated iC60 MCB)
- RATED INSULATION VOLTAGE (Ui): 500V
- RATED IMPULSE WITHSTAND VOLTAGE (Uimp): 6 kV
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- MOUNTING SUPPORT: Clip-on to iC60 Miniature Circuit Breaker
- WIDTH: 4 modules (90 mm)
- HEIGHT: 91 mm
- DEPTH: 73.5 mm
- INTERFACE/CONTROL:
- INDICATORS: Trip indicator, ON/OFF indicator
- TEST FUNCTION: Integrated test button for operational verification
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (terminals), IP40 (enclosure, when mounted in modular enclosure)
- OPERATING TEMPERATURE: -5 to 60 degrees C
- STORAGE TEMPERATURE: -40 to 85 degrees C
- MOUNTING STYLE: DIN rail mountable (via associated iC60 MCB)
- COMPATIBILITY/APPLICATION:
- COMPATIBLE CIRCUIT BREAKERS: SCHNEIDER ELECTRIC Acti 9 iC60 Miniature Circuit Breakers
- TARGET APPLICATIONS: Electrical distribution panels, machinery control circuits, building automation systems, and installations requiring residual current protection against indirect contact and fire hazards.
