SCHNEIDER ELECTRIC A9F17116 - Miniature Circuit Breaker
This device is a modular miniature circuit breaker from the Acti 9 iC60N series, engineered for overcurrent and short-circuit protection in industrial and commercial low-voltage electrical distribution systems. It provides reliable circuit isolation and protection for resistive and inductive loads, ensuring operational safety and system integrity in applications such as panel boards, machinery control circuits, and building infrastructure. Its thermal-magnetic trip unit offers protection against both overload and short-circuit conditions.
Technical Specifications:
- SERIES/FAMILY: Acti 9 iC60N
- COMPONENT TYPE: Miniature Circuit Breaker (MCB)
- ELECTRICAL SPECS:
- NOMINAL CURRENT: 16 A
- NUMBER OF POLES: 1P (Single Pole)
- TRIP CURVE: C-curve (Thermal-magnetic, for general applications with moderate inrush currents)
- RATED OPERATIONAL VOLTAGE (Ue): 230 VAC
- RATED INSULATION VOLTAGE (Ui): 500 V
- RATED IMPULSE WITHSTAND VOLTAGE (Uimp): 6 kV
- BREAKING CAPACITY (Icn): 6 kA at 230 VAC (IEC/EN 60898-1)
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- MOUNTING: DIN Rail
- MODULE WIDTH: 18 mm (1 module)
- TERMINAL TYPE: Tunnel terminals
- WIRE CAPACITY: 1 to 25 mm² (rigid), 1 to 16 mm² (flexible)
- INTERFACE/CONTROL:
- INDICATORS: Trip indicator, contact position indicator (ON/OFF)
- AUXILIARY COMPATIBILITY: Compatible with Acti 9 auxiliaries (e.g., OF, SD, iMN, iMX) for remote indication and control
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (Terminals), IP40 (Enclosed in modular enclosure)
- OPERATING TEMPERATURE: -35 to 70 °C
- STORAGE TEMPERATURE: -40 to 85 °C
- POLLUTION DEGREE: 3
- ALTITUDE: 0 to 2000 m without derating
- COMPATIBILITY/APPLICATION:
- APPLICATIONS: Overcurrent protection, short-circuit protection, circuit isolation
- TARGET SYSTEMS: Industrial control panels, commercial building distribution boards, residential electrical installations, machinery protection, HVAC systems
- STANDARDS: IEC/EN 60898-1, IEC/EN 60947-2
