SCHNEIDER ELECTRIC A9F18104 - Miniature Circuit Breaker
This SCHNEIDER ELECTRIC Acti 9 iC60N Miniature Circuit Breaker provides essential overcurrent and short-circuit protection for low-voltage electrical installations. Engineered for DIN rail mounting, this device ensures reliable circuit isolation and fault interruption in industrial, commercial, and residential distribution systems. It is specifically designed to protect against thermal overload and magnetic short-circuit events in circuits up to 4 Amperes.
Technical Specifications:
- SERIES/FAMILY: Acti 9 iC60N
- COMPONENT TYPE: Miniature Circuit Breaker (MCB)
- ELECTRICAL SPECS:
- NOMINAL CURRENT: 4 A
- NUMBER OF POLES: 1P (1 Pole)
- TRIP CURVE: C Curve
- NOMINAL OPERATIONAL VOLTAGE (Ue): 230/400 VAC (Phase-Neutral/Phase-Phase)
- NOMINAL INSULATION VOLTAGE (Ui): 500 VAC
- NOMINAL IMPULSE WITHSTAND VOLTAGE (Uimp): 6 kV
- BREAKING CAPACITY (Icn): 6 kA at 230/400 VAC (IEC/EN 60898-1)
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- MOUNTING: DIN Rail
- TERMINAL TYPE: Tunnel terminals (top and bottom)
- WIRE CAPACITY: 1 to 25 mm² (flexible), 1 to 35 mm² (rigid)
- MECHANICAL ENDURANCE: 20000 cycles
- ELECTRICAL ENDURANCE: 10000 cycles
- INTERFACE/CONTROL:
- INDICATION: Trip indicator, ON/OFF position indicator
- CONTROL TYPE: Toggle switch
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (terminals), IP40 (in enclosure)
- OPERATING TEMPERATURE: -35 to 70 degrees C
- STORAGE TEMPERATURE: -40 to 85 degrees C
- POLLUTION DEGREE: 3
- COMPATIBILITY/APPLICATION:
- APPLICATIONS: Industrial control panels, commercial building distribution boards, residential electrical systems, light-duty motor protection, general circuit protection.
- COMPATIBILITY: Compatible with Acti 9 auxiliaries and accessories (e.g., OF, SD, Vigi iC60).
