SCHNEIDER ELECTRIC A9N26929 - Miniature Circuit Breaker
This device is a modular miniature circuit breaker from the Acti 9 iC60N series, specifically designed for overcurrent and short-circuit protection in low-voltage electrical distribution systems. It provides essential circuit isolation and fault protection for industrial and commercial installations, adhering to IEC/EN standards for reliable operation. Its primary application is safeguarding electrical circuits and equipment against damage from excessive current conditions.
Technical Specifications:
- SERIES/FAMILY: Acti 9 iC60N
- COMPONENT TYPE: Miniature Circuit Breaker (MCB)
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 230 V AC
- NOMINAL CURRENT: 20 A
- POLES: 1P+N
- TRIPPING CURVE: C
- BREAKING CAPACITY: 6 kA (at 230 V AC, per IEC/EN 60898-1)
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Modular DIN Rail
- WIDTH: 2 x 9mm modules
- TERMINAL TYPE: Tunnel terminals (top and bottom)
- WIRE CAPACITY: 1 to 25 mm2 rigid, 1 to 16 mm2 flexible
- INTERFACE/CONTROL:
- INDICATION: ON/OFF position, Trip indication
- CONTROL TYPE: Toggle switch (manual operation)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (terminals), IP40 (front face in enclosure)
- MOUNTING STYLE: DIN Rail (35 mm symmetrical)
- OPERATING TEMPERATURE: -35 to 70 degrees C
- STORAGE TEMPERATURE: -40 to 85 degrees C
- POLLUTION DEGREE: 3 (per IEC/EN 60947-2)
- COMPATIBILITY/APPLICATION:
- PRIMARY FUNCTION: Overcurrent and short-circuit protection
- TARGET SYSTEMS: Low-voltage electrical distribution panels, industrial control circuits, commercial installations
- STANDARDS COMPLIANCE: IEC/EN 60898-1, IEC/EN 60947-2
- AUXILIARY COMPATIBILITY: Compatible with Acti 9 series auxiliaries (e.g., shunt trips, undervoltage releases, auxiliary contacts)
