SCHNEIDER ELECTRIC C10B3TM040 - Compact AC Servo Motor
This component is a SCHNEIDER ELECTRIC C10 Series permanent magnet synchronous AC servo motor, engineered for precise and dynamic motion control applications. It integrates seamlessly with compatible servo drives to deliver accurate speed, position, and torque regulation in industrial automation systems. The motor is suitable for demanding tasks requiring high responsiveness and repeatability, commonly found in packaging machinery, material handling systems, and small-scale machine tools.
Technical Specifications:
- SERIES/FAMILY: C10 Series AC Servo Motor
- COMPONENT TYPE: Permanent Magnet Synchronous AC Servo Motor
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 230VAC (Three-Phase)
- NOMINAL POWER: 0.4 kW (400 W)
- NOMINAL CURRENT: 1.2 A (Approximate)
- INSULATION CLASS: F
- MECHANICAL/PHYSICAL:
- NOMINAL TORQUE: 1.27 Nm
- NOMINAL SPEED: 3000 RPM
- PEAK TORQUE: 3.8 Nm (Typical)
- SHAFT TYPE: Smooth or Keyed, with flange mounting
- FRAME SIZE: Compact industrial standard (e.g., 60mm or 70mm square flange)
- INTERFACE/CONTROL:
- FEEDBACK: High-resolution absolute or incremental encoder (e.g., 17-bit or 20-bit)
- CONNECTION: Integrated power and feedback connectors
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (Housing and shaft seal)
- COOLING METHOD: Natural convection
- MOUNTING STYLE: Flange mount (IEC standard compatible)
- OPERATING TEMPERATURE: 0 to 40 degrees C
- COMPATIBILITY/APPLICATION:
- COMPATIBLE DRIVES: SCHNEIDER ELECTRIC Lexium series servo drives (e.g., Lexium 32, Lexium 28)
- APPLICATIONS: Precision positioning, speed control, and torque control in automated machinery, including small CNC machines, pick-and-place robots, labeling equipment, and printing presses.
