SCHNEIDER ELECTRIC C16F3TM125 - Motor Protection Circuit Breaker
This component is an industrial-grade Motor Protection Circuit Breaker (MPCB) from the SCHNEIDER ELECTRIC TeSys GV series, engineered for the protection and control of three-phase AC motors and inductive loads. It integrates precise thermal overload and instantaneous magnetic short-circuit protection, ensuring operational safety and equipment longevity in demanding industrial environments. The device provides manual motor control and reliable disconnection capabilities, critical for compliance with industrial safety standards.
Technical Specifications:
- SERIES/FAMILY: SCHNEIDER ELECTRIC TeSys GV Series
- COMPONENT TYPE: Motor Protection Circuit Breaker (MPCB)
- ELECTRICAL SPECS:
- NOMINAL CURRENT: 16 A
- POLES: 3-Pole
- TRIP UNIT TYPE: Thermal-Magnetic
- THERMAL TRIP ADJUSTMENT RANGE: 11 A to 16 A
- MAGNETIC TRIP LEVEL: Approximately 13 x In (208 A)
- NOMINAL OPERATIONAL VOLTAGE: Up to 690 VAC
- RATED IMPULSE WITHSTAND VOLTAGE (Uimp): 6 kV
- RATED SHORT-CIRCUIT BREAKING CAPACITY (Icu): 12.5 kA at 400/415 VAC
- MECHANICAL/PHYSICAL:
- OPERATION: Rotary Handle
- TERMINALS: Screw Clamp
- FORM FACTOR: Compact, Modular
- INTERFACE/CONTROL:
- PROTECTION FUNCTIONS: Overload Protection, Short-Circuit Protection
- AUXILIARY CONTACTS: Optional side or front mounted auxiliary contact blocks for status indication
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (Terminals), IP40 (Front Face)
- MOUNTING STYLE: 35mm DIN Rail
- COOLING METHOD: Natural Convection
- OPERATING TEMPERATURE: -20°C to +60°C
- COMPATIBILITY/APPLICATION: Direct-on-line (DOL) motor starters, industrial machinery, pump control, HVAC systems, conveyor systems, and general load protection in control panels.
