SCHNEIDER ELECTRIC TLXCDLTOFS36 - Synchronous Servo Motor
The SCHNEIDER ELECTRIC TLXCDLTOFS36 is a compact synchronous servo motor from the Lexium 32 series, engineered for precise and dynamic motion control in industrial automation. This motor integrates a multi-turn absolute encoder for accurate position feedback and is designed for direct integration with Lexium 32 servo drives, facilitating high-performance applications such as CNC machinery, robotics, material handling systems, and packaging equipment requiring stringent speed, torque, and positioning accuracy.
Technical Specifications:
- SERIES/FAMILY: Lexium 32 Servo Motors
- COMPONENT TYPE: Synchronous Servo Motor
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 230VAC or 400VAC (3-Phase)
- NOMINAL POWER: 0.36 kW (360W) - Specific to '36' variant
- NOMINAL CURRENT: Derived from power and voltage
- MECHANICAL/PHYSICAL:
- NOMINAL TORQUE: Derived from power and speed
- NOMINAL SPEED: 3000 RPM (Typical for series)
- SHAFT TYPE: Plain shaft
- BRAKE: With holding brake
- FRAME SIZE: Specific to 'C' code variant (e.g., 70mm or 100mm flange)
- MOTOR LENGTH: Specific to 'D' code variant
- INTERFACE/CONTROL:
- FEEDBACK DEVICE: Multi-turn absolute encoder
- ENCODER RESOLUTION: 128 increments/turn, 4096 turns (Typical for series)
- ELECTRICAL CONNECTION: Power and feedback connectors
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (Motor body), IP41 (Shaft end)
- COOLING METHOD: Natural convection
- MOUNTING STYLE: Flange mount
- COMPATIBILITY/APPLICATION:
- COMPATIBLE DRIVES: SCHNEIDER ELECTRIC Lexium 32 Servo Drives (LXM32 series)
- TARGET APPLICATIONS: High-precision positioning, speed, and torque control in CNC machines, robotics, automated assembly, and material handling systems.
