SCHNEIDER ELECTRIC XPEM3100D - Ethernet/IP Adapter Module
The SCHNEIDER ELECTRIC XPEM3100D is a Modicon X80 Ethernet/IP adapter module designed for distributed I/O architectures. It facilitates the integration of Modicon X80 input/output modules into industrial control systems utilizing the Ethernet/IP protocol, acting as a communication gateway between the X80 backplane and the Ethernet network. This module is critical for applications requiring robust, high-speed data exchange in process automation, discrete manufacturing, and machine control environments.
Technical Specifications:
- SERIES/FAMILY: Modicon X80
- COMPONENT TYPE: Ethernet/IP Adapter Module
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24VDC (supplied via X80 backplane)
- POWER CONSUMPTION: 2.5W (typical)
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Rack-mounted module
- MOUNTING: Standard Modicon X80 rack slot
- INTERFACE/CONTROL:
- COMMUNICATION PROTOCOL: Ethernet/IP (Scanner/Adapter)
- ETHERNET PORTS: 2 x RJ45
- ETHERNET DATA RATE: 10/100 Mbps
- NETWORK TOPOLOGY SUPPORT: Daisy-chain, Device Level Ring (DLR)
- I/O CAPACITY: Supports up to 64 Modicon X80 I/O modules
- DIAGNOSTICS: LED indicators for network status, module status, and I/O activity
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20
- COOLING METHOD: Convection cooling
- OPERATING TEMPERATURE: 0 to 60 degrees Celsius
- COMPATIBILITY/APPLICATION:
- COMPATIBLE SYSTEMS: Modicon X80 I/O platform, Modicon M580, Modicon M340, and other Ethernet/IP enabled PLCs/PACs
- TARGET APPLICATIONS: Distributed control systems, remote I/O expansion, process automation, machine automation, energy management systems
