SCHNEIDER ELECTRIC XPSMCMC10804B - Configurable Safety Controller Base Module
The SCHNEIDER ELECTRIC XPSMCMC10804B is a Modicon XPSMCM series configurable safety controller base module, engineered for the centralized management of critical safety functions in industrial machinery. This unit provides programmable safety logic for applications requiring compliance with Performance Level e (PL e) and Safety Integrity Level 3 (SIL 3), integrating safety inputs and outputs for comprehensive machine safeguarding. It is designed for deployment in diverse industrial environments, including robotics, material handling, packaging, and automated assembly lines.
Technical Specifications:
- SERIES/FAMILY: Modicon XPSMCM
- COMPONENT TYPE: Configurable Safety Controller Base Module
- ELECTRICAL SPECS:
- NOMINAL SUPPLY VOLTAGE: 24 VDC
- POWER CONSUMPTION: 5 W (typical)
- SAFETY INPUTS: 8 configurable digital inputs
- SAFETY OUTPUTS: 4 configurable OSSD (Output Signal Switching Device) pairs
- AUXILIARY OUTPUTS: 2 solid-state auxiliary outputs
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Modular, DIN rail mountable
- TERMINATION: Removable screw terminals
- INTERFACE/CONTROL:
- CONFIGURATION PORT: USB Type B for software connection
- EXPANSION BUS: Integrated bus for safety expansion modules (I/O, communication)
- SAFETY STANDARDS: Conforms to EN/ISO 13849-1 (up to PL e), IEC 61508 (up to SIL 3), IEC 62061 (up to SIL CL 3)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20
- OPERATING TEMPERATURE: 0 to 55 degrees Celsius
- MOUNTING: 35 mm DIN rail
- COOLING: Natural convection
- COMPATIBILITY/APPLICATION:
- TARGET APPLICATIONS: Emergency stop monitoring, guard interlock, light curtain integration, two-hand control, safety mat monitoring, and other machine safety functions.
- SYSTEM INTEGRATION: Suitable for integration into industrial control panels requiring flexible, programmable safety logic for complex machinery.
