SCHNEIDER ELECTRIC XVB7C64 - Modular Tower Light Unit
The SCHNEIDER ELECTRIC XVB7C64 is a Harmony XVB series modular signaling unit designed for visual status indication in industrial control systems. This component provides a continuous green light output, operating on a 24V AC/DC supply, and is engineered for integration into multi-level tower light assemblies to convey machine operational states, process conditions, or safety alerts. It serves as a critical visual feedback element for maintenance engineers and operators in diverse automation and manufacturing environments.
Technical Specifications:
- SERIES/FAMILY: Harmony XVB
- COMPONENT TYPE: Modular Tower Light Unit
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24V AC/DC
- POWER CONSUMPTION: 1.2W (typical)
- FREQUENCY: 50/60 Hz (for AC operation)
- MECHANICAL/PHYSICAL:
- DIAMETER: 70 mm
- LIGHT TYPE: Continuous
- COLOR: Green
- FORM FACTOR: Stackable module for tower light assembly
- INTERFACE/CONTROL:
- CONTROL INPUT: Direct electrical connection
- FEEDBACK: Visual indication
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (when correctly assembled with base and cap)
- OPERATING TEMPERATURE: -25°C to +70°C
- MOUNTING STYLE: Designed for modular stacking onto XVB bases
- COMPATIBILITY/APPLICATION:
- COMPATIBILITY: Compatible with Harmony XVB series bases, fixing plates, and other light/sound units
- APPLICATION: Machine status indication, fault signaling, process step visualization, safety zone alerts in industrial machinery, control panels, and material handling systems
