SICK 1061715 - Photoelectric Sensor
The SICK WTB4-3P2161 is a miniature photoelectric proximity sensor from the W4-3 series, engineered for reliable object detection with integrated background suppression. This optical sensing device provides a solid-state PNP switching output, making it suitable for precise presence sensing and position monitoring in automated assembly lines, packaging machinery, material handling systems, and robotic applications. Its compact form factor and robust design facilitate integration into space-constrained industrial environments requiring dependable optical control technology.
Technical Specifications:
- SERIES/FAMILY: W4-3 Miniature Photoelectric Sensors
- COMPONENT TYPE: Photoelectric proximity sensor, diffuse with background suppression
- ELECTRICAL SPECS:
- SUPPLY VOLTAGE: 10 V DC to 30 V DC
- CURRENT CONSUMPTION: Max. 20 mA
- OUTPUT TYPE: PNP
- SWITCHING OUTPUT: Light/dark switching, selectable
- SWITCHING FREQUENCY: 1,000 Hz
- CONNECTION: M8, 3-pin male connector
- MECHANICAL/PHYSICAL:
- SENSING PRINCIPLE: Diffuse sensor with background suppression
- SENSING RANGE: 30 mm to 200 mm, adjustable
- LIGHT SOURCE: PinPoint LED, Red light (650 nm)
- HOUSING MATERIAL: ABS/PC (housing), PMMA (front screen)
- FORM FACTOR: Miniature rectangular housing
- INTERFACE/CONTROL:
- ADJUSTMENT: Potentiometer for sensing range
- OUTPUT FUNCTION: Single switching output
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP67
- OPERATING TEMPERATURE: -40 °C to +60 °C
- MOUNTING STYLE: Through-hole, M3 screw mounting
- COMPATIBILITY/APPLICATION:
- TARGET APPLICATIONS: Object detection, presence sensing, position monitoring in automated assembly, packaging machinery, material handling, and robotics.
