SICK 1076676 - Photoelectric Proximity Sensor
The SICK WTB4-3P2161 is a compact photoelectric proximity sensor from the W4-3 series, engineered for reliable object detection with background suppression in industrial automation environments. Utilizing PinPoint LED technology and a PNP switching output, this sensor provides precise presence sensing for applications such as material handling, packaging machinery, and assembly lines, ensuring robust performance in confined spaces. Its integrated potentiometer allows for fine-tuned sensing range adjustment, optimizing detection accuracy across various target materials.
Technical Specifications:
- SERIES/FAMILY: W4-3 Series
- COMPONENT TYPE: Photoelectric Proximity Sensor, Diffuse with Background Suppression
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 10 V DC to 30 V DC
- CURRENT CONSUMPTION: <= 20 mA (no load)
- OUTPUT TYPE: PNP, Light Switching (NO)
- SWITCHING CURRENT: Max. 100 mA
- SWITCHING FREQUENCY: 1,000 Hz
- RESPONSE TIME: 0.5 ms
- PROTECTION CLASS: III
- MECHANICAL/PHYSICAL:
- SENSING PRINCIPLE: Diffuse with Background Suppression
- LIGHT SOURCE: PinPoint LED, Red Light
- SENSING RANGE: 5 mm to 150 mm (adjustable via potentiometer)
- HOUSING MATERIAL: ABS/PC (housing), PMMA (front screen)
- ADJUSTMENT: Potentiometer, 270 degrees
- DIMENSIONS: 16 mm x 39.5 mm x 12 mm
- WEIGHT: 10 g
- INTERFACE/CONTROL:
- CONNECTION TYPE: M8 3-pin Male Connector
- INDICATORS: Yellow LED (switching output), Green LED (operating indicator)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP67
- OPERATING TEMPERATURE: -40 degrees C to +60 degrees C
- STORAGE TEMPERATURE: -40 degrees C to +75 degrees C
- MOUNTING STYLE: Through-hole (M3)
- COOLING METHOD: Ambient Air
- COMPATIBILITY/APPLICATION: Object detection, presence sensing, small parts detection, material handling systems, packaging machinery, assembly automation, robotics.
