SICK 1089630 - Incremental Encoder
The SICK 1089630 is an incremental encoder from the DFS60 series, engineered for precise rotational position and speed feedback in industrial automation applications. This device provides TTL/RS-422 complementary output signals, making it suitable for integration into motion control systems, machine tools, and material handling equipment requiring high-resolution pulse generation. Its robust design ensures reliable operation in demanding industrial environments.
Technical Specifications:
- SERIES/FAMILY: DFS60
- COMPONENT TYPE: Incremental Encoder
- ELECTRICAL SPECS:
- SUPPLY VOLTAGE: 4.5 VDC to 5.5 VDC
- CURRENT CONSUMPTION: Max. 80 mA (no load)
- OUTPUT SIGNAL: TTL/RS-422
- OUTPUT TYPE: Complementary (A, A-bar, B, B-bar, Z, Z-bar)
- MAX OUTPUT FREQUENCY: 600 kHz
- MECHANICAL/PHYSICAL:
- HOUSING DIAMETER: 60 mm
- SHAFT TYPE: Solid shaft
- SHAFT DIAMETER: Standard solid shaft (e.g., 6 mm or 10 mm, specific to variant)
- RESOLUTION: 1024 pulses per revolution (PPR)
- MAX OPERATIONAL SPEED: 6,000 RPM
- INTERFACE/CONTROL:
- FEEDBACK SIGNALS: A, B, Z (with complementary inverted signals)
- CONNECTION TYPE: Radial cable, standard length (e.g., 1.5 m)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (housing), IP67 (shaft entry)
- OPERATING TEMPERATURE: -30 °C to +100 °C
- MOUNTING STYLE: Face mount flange
- COMPATIBILITY/APPLICATION: Motion control systems, robotics, CNC machinery, packaging equipment, material handling, length measurement, speed monitoring.
