DESCRIZIONE PRODOTTO
SICK 1089658 - Photoelectric Proximity Sensor, Background Suppression
The SICK WTB4-3P2161 is a miniature photoelectric proximity sensor with background suppression, engineered for precise object detection in confined industrial environments. Utilizing PinPoint LED technology and a PNP solid-state output, this sensor provides reliable presence sensing for automated machinery and material handling applications. Its compact form factor and M8 connector facilitate integration into high-density automation systems requiring robust optical sensing capabilities.
Technical Specifications:
- SERIES/FAMILY: W4-3 Miniature Photoelectric Sensors
- COMPONENT TYPE: Photoelectric proximity sensor, background suppression
- ELECTRICAL SPECS:
- SUPPLY VOLTAGE: 10 VDC to 30 VDC
- CURRENT CONSUMPTION: < 20 mA
- OUTPUT TYPE: 1 x PNP, light/dark switching selectable
- SWITCHING CURRENT: Max. 100 mA
- RESPONSE TIME: < 0.5 ms
- MECHANICAL/PHYSICAL:
- SENSING PRINCIPLE: Photoelectric proximity sensor, background suppression
- LIGHT SOURCE: PinPoint LED, red light (650 nm)
- SENSING RANGE: 30 mm to 125 mm, adjustable
- HOUSING MATERIAL: ABS/PC plastic
- FORM FACTOR: Miniature rectangular
- INTERFACE/CONTROL:
- OUTPUT: 1 x PNP switching output
- CONNECTION: M8 male connector, 3-pin
- ADJUSTMENT: Potentiometer for sensing range
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP67
- OPERATING TEMPERATURE: -40 °C to +60 °C
- MOUNTING STYLE: Through-hole, via M3 screws
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Industrial automation systems, PLC-controlled machinery, robotic cells, conveyor systems
- SPECIFIC MACHINE TYPES: Packaging machines, material handling equipment, assembly lines, small parts detection
