SICK 1094780 - Photoelectric Proximity Sensor
The SICK WTB4-3P2161 is a miniature photoelectric proximity sensor engineered for precise object detection in industrial automation environments. This sensor employs background suppression technology to accurately identify objects within a defined sensing range, effectively ignoring reflective or varying backgrounds. It provides a reliable PNP light-switching output for seamless integration into control systems requiring discrete signal input for applications such as material handling, packaging, and assembly.
Technical Specifications:
- SERIES/FAMILY: W4-3 Miniature Photoelectric Sensors
- COMPONENT TYPE: Photoelectric proximity sensor, background suppression
- ELECTRICAL SPECS:
- SUPPLY VOLTAGE: 10 V DC ... 30 V DC
- CURRENT CONSUMPTION: Max. 20 mA
- OUTPUT TYPE: PNP, light switching
- SWITCHING CURRENT: Max. 100 mA
- SWITCHING FREQUENCY: 1,000 Hz
- RESPONSE TIME: 0.5 ms
- MECHANICAL/PHYSICAL:
- SENSING PRINCIPLE: Photoelectric proximity sensor, background suppression
- SENSING RANGE: 20 mm ... 150 mm (adjustable via potentiometer)
- LIGHT SOURCE: PinPoint LED, Red light (650 nm)
- HOUSING MATERIAL: ABS/PC
- OPTICS MATERIAL: PMMA
- CONNECTION: M8 3-pin male connector
- FORM FACTOR: Miniature cubic housing
- INTERFACE/CONTROL:
- OUTPUT FUNCTION: Light switching
- ADJUSTMENT: Potentiometer for sensing range
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP67
- OPERATING TEMPERATURE: -40 °C ... +60 °C
- MOUNTING STYLE: Through-hole, via M3 screws
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Automated assembly lines, packaging machinery, material handling systems, small parts detection, robotics
- SPECIFIC MACHINE TYPES: Conveyor systems, pick-and-place units, sorting machines
