DESCRIZIONE PRODOTTO
SICK 2105106 - Safety Light Curtain Sender Unit
The SICK 2105106 is a sender unit component of the C4000 Standard safety light curtain series, engineered for electro-sensitive protective equipment (ESPE) applications. This Type 4 device provides reliable optical emission for personnel protection in hazardous industrial environments. It is designed for integration into machine safety systems requiring access protection, hazardous point safeguarding, and perimeter guarding in applications such as robotics, automated assembly, and material handling.
Technical Specifications:
- SERIES/FAMILY: C4000 Standard
- COMPONENT TYPE: Safety Light Curtain Sender Unit
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24 VDC
- VOLTAGE RANGE: 19.2 VDC to 28.8 VDC
- POWER CONSUMPTION: 10 W (typical for system, sender contributes)
- PROTECTION CLASS: III (IEC 61140)
- MECHANICAL/PHYSICAL:
- HOUSING MATERIAL: Aluminum (ALMGSI 0.5)
- FRONT SCREEN MATERIAL: Polymethyl methacrylate (PMMA)
- PROFILE DIMENSIONS: 40 mm x 48 mm (W x D)
- PROTECTIVE FIELD HEIGHT: Dependent on paired receiver unit and system configuration
- INTERFACE/CONTROL:
- CONNECTION TYPE: M12 male connector, 5-pin
- OPTICAL INTERFACE: Infrared light, modulated
- SAFETY INTEGRATION: Part of a Type 4 ESPE system (IEC 61496-1)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (EN 60529)
- OPERATING TEMPERATURE: -30 °C to +55 °C
- STORAGE TEMPERATURE: -30 °C to +70 °C
- MOUNTING STYLE: Compatible with standard C4000 mounting brackets (e.g., swivel, side, rear)
- COMPATIBILITY/APPLICATION:
- COMPATIBILITY: SICK C4000 Standard Receiver Units
- APPLICATION: Personnel protection, access control, hazardous point safeguarding in industrial machinery, robotic work cells, automated production lines, material handling systems
