SICK 6008781 - Photoelectric Sensor, Background Suppression
The SICK WTB4-3P2161 is a compact photoelectric sensor from the W4-3 product family, engineered for precise object detection with background suppression capabilities. It utilizes PinPoint LED technology and a PNP switching output, making it suitable for applications requiring reliable presence detection in confined spaces, such as material handling, packaging machinery, and automated assembly lines. This device provides stable sensing performance across various target materials and colors.
Technical Specifications:
- SERIES/FAMILY: W4-3
- COMPONENT TYPE: Photoelectric Sensor, Background Suppression
- ELECTRICAL SPECS:
- SUPPLY VOLTAGE: 10 V DC to 30 V DC
- CURRENT CONSUMPTION: 20 mA (no load)
- OUTPUT TYPE: PNP, Light/Dark Switching (selectable)
- SWITCHING CURRENT: 100 mA
- SWITCHING FREQUENCY: 1000 Hz
- RESPONSE TIME: 0.5 ms
- MECHANICAL/PHYSICAL:
- SENSING PRINCIPLE: Photoelectric Proximity Sensor, Background Suppression
- SENSING RANGE: 5 mm to 150 mm (adjustable via potentiometer)
- LIGHT SOURCE: PinPoint LED, Red Light (650 nm)
- HOUSING MATERIAL: ABS/PC
- OPTICS MATERIAL: PMMA
- CONNECTION: M8 3-pin Male Connector
- FORM FACTOR: Compact, Cubic Housing
- INTERFACE/CONTROL:
- OUTPUTS: 1 x PNP
- ADJUSTMENT: Potentiometer for Sensing Range
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP67
- OPERATING TEMPERATURE: -40 °C to +60 °C
- MOUNTING STYLE: Through-hole or Bracket Mount
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: General Industrial Automation, Material Handling, Packaging Machinery, Automated Assembly Lines, Robotics
- FUNCTION: Object Presence Detection, Small Parts Detection, Counting Applications
