SICK 6013261 - Incremental Encoder
The SICK 6013261 is an incremental encoder from the DFS60 series, engineered for precise angular position and speed feedback in industrial automation. This device generates incremental pulse signals, compatible with HTL/TTL interfaces, making it suitable for integration into machine tools, packaging machinery, material handling systems, and general motion control applications requiring robust and accurate rotational sensing. It provides essential data for closed-loop control systems and position monitoring.
Technical Specifications:
- SERIES/FAMILY: DFS60
- COMPONENT TYPE: Incremental Encoder
- ELECTRICAL SPECS:
- OPERATING VOLTAGE: 4.5 V ... 32 V DC
- CURRENT CONSUMPTION: Max. 60 mA (without load)
- OUTPUT FREQUENCY: Max. 600 kHz
- ELECTRICAL INTERFACE: Push-pull (HTL/TTL compatible)
- MECHANICAL/PHYSICAL:
- RESOLUTION: 1024 pulses per revolution (PPR)
- SHAFT TYPE: Solid shaft, 6 mm diameter
- HOUSING DIAMETER: 60 mm
- MAX. MECHANICAL SPEED: 6,000 rpm
- MAX. ELECTRICAL SPEED: 6,000 rpm
- STARTING TORQUE: 0.5 Ncm (at 20 °C)
- INTERFACE/CONTROL:
- OUTPUT CHANNELS: A, B, Z, and inverted signals (A-, B-, Z-)
- CONNECTION TYPE: Cable, radial
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (shaft side), IP67 (housing side)
- OPERATING TEMPERATURE: -30 °C ... +100 °C
- MOUNTING STYLE: Face mount flange
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Motion control systems, servo drives, frequency inverters, PLC-based control
- APPLICATIONS: Position feedback, speed monitoring, length measurement, cut-to-length operations, robotics, conveyor systems
