SICK 6025680 - Photoelectric Sensor, Background Suppression
The SICK WTB4-3P2161 is a miniature photoelectric sensor from the W4-3 product family, engineered for precise object detection using background suppression technology. This compact device provides reliable presence sensing in industrial automation environments, utilizing a PinPoint LED for accurate detection regardless of object color or surface texture. It is suitable for integration into material handling systems, packaging machinery, assembly lines, and robotic applications requiring robust and space-efficient sensing solutions.
Technical Specifications:
- SERIES/FAMILY: W4-3 Miniature Photoelectric Sensors
- COMPONENT TYPE: Photoelectric Sensor, Background Suppression
- ELECTRICAL SPECS:
- SUPPLY VOLTAGE: 10 VDC to 30 VDC
- CURRENT CONSUMPTION: Max. 20 mA (no load)
- OUTPUT TYPE: PNP
- SWITCHING MODE: Light/Dark switching (selectable)
- SWITCHING FREQUENCY: 1000 Hz
- RESPONSE TIME: 0.5 ms
- MECHANICAL/PHYSICAL:
- HOUSING MATERIAL: ABS/PC
- LIGHT SOURCE: PinPoint LED, Red light
- SENSING PRINCIPLE: Background suppression
- SENSING RANGE: 20 mm to 100 mm (adjustable)
- ADJUSTMENT METHOD: Potentiometer
- HOUSING FORM FACTOR: Compact rectangular housing
- INTERFACE/CONTROL:
- ELECTRICAL CONNECTION: M8, 3-pin male connector
- OUTPUT FUNCTION: 1 x PNP, normally open (NO) / normally closed (NC) selectable
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP67
- OPERATING TEMPERATURE: -40 °C to +60 °C
- MOUNTING TYPE: Through-hole, M3 screws
- COMPATIBILITY/APPLICATION:
- TARGET APPLICATIONS: Material handling, packaging automation, assembly lines, robotics, general industrial object detection
- KEY FEATURES: Background suppression, PinPoint technology for precise detection, robust housing for industrial environments
