ASEA BROWN BOVERI 1SDA013575R1 - Molded Case Circuit Breaker
This device is a 3-pole molded case circuit breaker from the ABB SACE Tmax T4N series, engineered for overcurrent and short-circuit protection in industrial and commercial electrical distribution systems. It integrates an advanced PR221DS-LS/I electronic trip unit, providing adjustable long-time, short-time, and instantaneous protection functions. Designed for fixed installation with front terminals, this MCCB ensures reliable circuit isolation and fault clearance in applications requiring precise current management and system safety.
Technical Specifications:
- SERIES/FAMILY: SACE Tmax T4N
- COMPONENT TYPE: Molded Case Circuit Breaker (MCCB)
- ELECTRICAL SPECS:
- NOMINAL CURRENT (In): 250 A
- POLES: 3
- NOMINAL OPERATIONAL VOLTAGE (Ue): Up to 690 VAC
- NOMINAL INSULATION VOLTAGE (Ui): 1000 V
- NOMINAL IMPULSE WITHSTAND VOLTAGE (Uimp): 8 kV
- NOMINAL FREQUENCY: 50/60 Hz
- NOMINAL SHORT-CIRCUIT BREAKING CAPACITY (Icu): 36 kA at 400/415 VAC
- NOMINAL SERVICE SHORT-CIRCUIT BREAKING CAPACITY (Ics): 100% of Icu
- TRIP UNIT TYPE: Electronic, PR221DS-LS/I
- PROTECTION FUNCTIONS: Long-time (L), Short-time (S), Instantaneous (I)
- MECHANICAL/PHYSICAL:
- FRAME SIZE: T4
- MOUNTING TYPE: Fixed
- TERMINAL TYPE: Front
- OPERATION: Manual toggle
- INTERFACE/CONTROL:
- TRIP UNIT DISPLAY: Digital display for settings and diagnostics
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (with front terminals, without additional enclosures)
- COOLING METHOD: Natural air convection
- OPERATING TEMPERATURE: -25 to +70 degrees C
- COMPATIBILITY/APPLICATION:
- APPLICATIONS: Overcurrent and short-circuit protection in low-voltage electrical distribution, motor protection, generator protection, transformer protection.
- INSTALLATION: Industrial panels, commercial switchboards, machinery control systems.
