ASEA BROWN BOVERI 1SDA062172R1 - Molded Case Circuit Breaker
The ABB SACE Tmax XT2N 160 is a three-pole molded case circuit breaker engineered for robust electrical circuit protection in low voltage distribution systems. Featuring a thermomagnetic trip unit, this device provides reliable overload and short-circuit protection for industrial machinery, motor control centers, and commercial building infrastructure. It is designed for fixed installation, ensuring critical fault current interruption and system integrity.
Technical Specifications:
- SERIES/FAMILY: SACE Tmax XT2
- COMPONENT TYPE: Molded Case Circuit Breaker (MCCB)
- ELECTRICAL SPECS:
- NOMINAL FRAME CURRENT: 160A
- NUMBER OF POLES: 3
- RATED OPERATIONAL VOLTAGE (Ue): 400/415VAC
- RATED INSULATION VOLTAGE (Ui): 1000V
- RATED IMPULSE WITHSTAND VOLTAGE (Uimp): 8kV
- RATED ULTIMATE SHORT-CIRCUIT BREAKING CAPACITY (Icu): 36kA at 400VAC
- TRIP UNIT TYPE: Thermomagnetic (TMD)
- MECHANICAL/PHYSICAL:
- FRAME SIZE: XT2
- MOUNTING TYPE: Fixed
- TERMINAL TYPE: Front terminals
- INTERFACE/CONTROL:
- PROTECTION FUNCTIONS: Overload (Thermal), Short-circuit (Magnetic)
- THERMAL PROTECTION ADJUSTABILITY (Ir): Adjustable (typically 0.7 to 1.0 x In)
- MAGNETIC PROTECTION ADJUSTABILITY (Ii): Fixed (typically 10 x In)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (with terminal covers)
- COOLING METHOD: Natural Convection
- MOUNTING STYLE: Panel Mount
- COMPATIBILITY/APPLICATION:
- APPLICATIONS: Low Voltage Power Distribution, Motor Protection, Generator Protection, Industrial Machinery, Commercial Building Infrastructure
- COMPATIBILITY: Designed for integration into switchboards, control panels, and electrical distribution systems
