ALLEN BRADLEY 100S-E190KN12C - Guardmaster Safety Relay
This ALLEN BRADLEY Guardmaster 100S-E series safety relay is engineered for monitoring critical safety devices within industrial automation systems. It provides robust safety interlocking, emergency stop, and machine guarding functionalities, facilitating compliance with international safety standards such as ISO 13849-1 and IEC 62061. The module processes safety input signals to control machine power, ensuring operator protection and system integrity in high-risk industrial environments.
Technical Specifications:
- SERIES/FAMILY: Guardmaster 100S-E
- COMPONENT TYPE: Safety Relay
- ELECTRICAL SPECS:
- NOMINAL COIL VOLTAGE: 12V DC
- SAFETY OUTPUTS: Multiple Normally Open (N.O.) safety contacts (variant dependent)
- AUXILIARY OUTPUTS: Normally Closed (N.C.) auxiliary contacts (variant dependent)
- CONTACT RATING: 6A @ 250VAC / 24VDC (typical for resistive loads)
- POWER CONSUMPTION: 2.5W (typical)
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Compact DIN Rail Mount Module
- TERMINATION: Fixed Screw Terminals
- DIMENSIONS: Standard industrial relay footprint (specific to variant)
- INTERFACE/CONTROL:
- INPUTS: Dual-channel safety inputs for E-stop buttons, light curtains, safety gates, and other OSSD devices
- RESET FUNCTION: Manual or Automatic Reset capability (variant dependent)
- INDICATORS: LED status indicators for power, input, and output status
- SAFETY CATEGORY: Up to PLe/Category 4 per ISO 13849-1 SIL 3 per IEC 62061
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (Terminal Protection), IP40 (Enclosure)
- MOUNTING: 35mm DIN Rail
- OPERATING TEMPERATURE: 0 to 55 degrees C
- STORAGE TEMPERATURE: -40 to 85 degrees C
- COMPATIBILITY/APPLICATION:
- APPLICATIONS: Emergency Stop circuits, Machine Guarding, Safety Gate Monitoring, Light Curtain Integration, Two-Hand Control applications
- COMPATIBILITY: Integrates with various safety input devices and industrial control systems requiring functional safety.
