SCHNEIDER ELECTRIC 16649 - 3-Pole Contactor
The SCHNEIDER ELECTRIC 16649 (LC1D09M7) is a TeSys D series 3-pole contactor engineered for robust industrial motor control and resistive load switching. It features a 9A AC-3 operational current rating and is actuated by a 220VAC 50/60Hz coil, providing reliable electromechanical switching for automation systems, HVAC, and power distribution circuits. This device is designed for integration into control panels requiring precise and durable load management.
Technical Specifications:
- SERIES/FAMILY: TeSys D
- COMPONENT TYPE: 3-Pole Contactor
- ELECTRICAL SPECS:
- NOMINAL OPERATIONAL CURRENT (AC-3): 9A at <= 440V
- NOMINAL OPERATIONAL CURRENT (AC-1): 25A at <= 690V
- NOMINAL OPERATIONAL VOLTAGE (POWER CIRCUIT): 690V AC 50/60Hz
- COIL VOLTAGE: 220VAC 50/60Hz
- POWER RATING (AC-3, 3-PHASE): 2.2 kW at 220/230V 4 kW at 380/400V 4 kW at 415V 4 kW at 440V 5.5 kW at 500V 5.5 kW at 660/690V
- NUMBER OF POLES: 3P
- AUXILIARY CONTACTS: 1 NO + 1 NC (built-in)
- MECHANICAL/PHYSICAL:
- TERMINALS: Screw clamp terminals
- INTERFACE/CONTROL:
- CONTROL TYPE: Electromagnetically actuated coil
- FEEDBACK: Integrated 1 NO + 1 NC auxiliary contacts for status indication
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (front face)
- OPERATING TEMPERATURE: -5 to 60 degrees C
- COOLING METHOD: Natural convection
- MOUNTING STYLE: 35mm DIN rail or panel mounting with screws
- COMPATIBILITY/APPLICATION: Motor control circuits, resistive load switching, lighting systems, heating applications, power distribution, industrial automation panels.
