SICK 1058261 - Incremental Encoder
This SICK DFS60 series incremental encoder provides precise rotational position and speed feedback for industrial automation applications. Utilizing a 60mm housing and a 6mm solid shaft, it generates 1024 pulses per revolution via a TTL/RS-422 electrical interface. Engineered for robust operation, this component is suitable for integration into machine tools, packaging systems, and material handling equipment requiring reliable motion control data.
Technical Specifications:
- SERIES/FAMILY: DFS60
- COMPONENT TYPE: Incremental Encoder
- ELECTRICAL SPECS:
- SUPPLY VOLTAGE: 4.5 VDC to 5.5 VDC
- CURRENT CONSUMPTION: Max. 40 mA (without load)
- OUTPUT FREQUENCY: Max. 300 kHz
- OUTPUT TYPE: TTL/RS-422 (Push-pull)
- MECHANICAL/PHYSICAL:
- HOUSING DIAMETER: 60 mm
- SHAFT TYPE: Solid shaft
- SHAFT DIAMETER: 6 mm
- PULSES PER REVOLUTION: 1024
- MAXIMUM MECHANICAL SPEED: 6,000 rpm
- MAXIMUM ELECTRICAL SPEED: 3,000 rpm
- STARTING TORQUE: 0.5 Ncm (at 20 °C)
- INTERFACE/CONTROL:
- OUTPUT CHANNELS: A, B, Z, A-, B-, Z-
- ELECTRICAL INTERFACE: TTL/RS-422
- CONNECTION TYPE: Cable, 8-pin, universal
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (shaft side), IP67 (housing side)
- OPERATING TEMPERATURE: -30 °C to +100 °C
- MOUNTING STYLE: Face mount flange
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: General industrial automation, motion control, position sensing, speed measurement
- MACHINE TYPES: Machine tools, packaging machinery, textile manufacturing equipment, robotics, material handling systems
