SICK 1201441 - Safety Light Curtain
The SICK deTec4 Core 1201441 is a Type 4 electro-sensitive protective equipment (ESPE) designed for robust personnel protection in industrial environments. This safety light curtain provides reliable finger detection, safeguarding operators from hazardous machinery by immediately stopping operations upon intrusion into the defined protection field. It is engineered for integration into safety-critical applications requiring Performance Level e (PL e) and Safety Integrity Level 3 (SIL3) compliance, commonly found in automated manufacturing, assembly lines, and material handling systems.
Technical Specifications:
- SERIES/FAMILY: deTec4 Core
- COMPONENT TYPE: Safety Light Curtain
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24V DC
- VOLTAGE RANGE: 19.2 V DC ... 28.8 V DC
- CURRENT CONSUMPTION: Max. 50 mA (per unit, typical for 300mm)
- MECHANICAL/PHYSICAL:
- PROTECTION FIELD HEIGHT: 300 mm
- RESOLUTION: 30 mm (Finger Protection)
- SCANNING RANGE: 0.3 m ... 10 m
- HOUSING MATERIAL: Aluminum extrusion
- FRONT SCREEN MATERIAL: Polyamide (PA)
- INTERFACE/CONTROL:
- OUTPUTS: 2 x OSSD (PNP, short-circuit protected, cross-circuit monitored)
- INPUTS: 1 x Reset/Restart Interlock, 1 x External Device Monitoring (EDM)
- CONNECTION TYPE: M12 male connector, 5-pin
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65
- OPERATING TEMPERATURE: -30 °C ... +55 °C
- MOUNTING STYLE: Standard mounting brackets (e.g., swivel mounts, side brackets)
- COMPATIBILITY/APPLICATION:
- SAFETY STANDARD: IEC 61496-1, IEC 61496-2 (Type 4)
- SAFETY INTEGRITY LEVEL: SIL3 (IEC 61508)
- PERFORMANCE LEVEL: PL e (ISO 13849-1)
- TARGET APPLICATIONS: Machine safeguarding, access protection, hazardous area protection, robotic cells, presses, automated assembly lines
