SICK 2095591 - Photoelectric Sensor, Background Suppression
The SICK 2095591 is a W4-3 series miniature photoelectric sensor engineered for precise object detection in industrial automation environments. This diffuse sensor with integrated background suppression technology provides reliable presence sensing, utilizing a red light LED and a PNP switching output. It is specifically designed for applications requiring accurate detection of objects regardless of their color or surface properties, commonly deployed in automated assembly, packaging, and material handling systems.
Technical Specifications:
- SERIES/FAMILY: W4-3 Series
- COMPONENT TYPE: Photoelectric sensor, diffuse mode with background suppression
- ELECTRICAL SPECS:
- SUPPLY VOLTAGE: 10 V DC to 30 V DC
- CURRENT CONSUMPTION: <= 20 mA (no load)
- OUTPUT TYPE: PNP, light/dark switching (selectable)
- OUTPUT CURRENT: Max. 100 mA
- SWITCHING FREQUENCY: 1,000 Hz
- RESPONSE TIME: 0.5 ms
- MECHANICAL/PHYSICAL:
- HOUSING MATERIAL: ABS/PC (housing), PMMA (front screen)
- LIGHT SOURCE: Red light LED
- CONNECTION: M8 4-pin male connector
- FORM FACTOR: Miniature rectangular housing
- INTERFACE/CONTROL:
- OUTPUTS: 1 x PNP switching output
- INDICATORS: LED for switching status, LED for operating reserve
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP67
- OPERATING TEMPERATURE: -40 °C to +60 °C
- STORAGE TEMPERATURE: -40 °C to +75 °C
- COOLING METHOD: Passive convection
- MOUNTING STYLE: Through-hole mounting via M3 screws
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Automated assembly lines, packaging machinery, material handling equipment, robotics
- FUNCTION: Object presence detection, position sensing, small part detection, conveyor control
