SICK 5308071 - Safety Light Curtain
The SICK 5308071 is a deTec4 Core series Type 4 safety light curtain, engineered for reliable finger protection in industrial environments. This sender/receiver pair provides a 300 mm protective field with 14 mm resolution, ensuring personnel safety at hazardous points and access areas. It integrates directly into machine safety circuits via OSSD outputs, compliant with IEC 61496-1 and ISO 13849-1 standards for high-level safety integrity.
Technical Specifications:
- SERIES/FAMILY: deTec4 Core
- COMPONENT TYPE: Safety Light Curtain (Sender/Receiver Pair)
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24V DC (19.2 V DC ... 28.8 V DC)
- CURRENT CONSUMPTION: Sender: 70 mA Receiver: 100 mA (typical)
- MECHANICAL/PHYSICAL:
- PROTECTIVE FIELD HEIGHT: 300 mm
- RESOLUTION: 14 mm (Finger Protection)
- SCANNING RANGE: 0.3 m ... 10 m
- HOUSING MATERIAL: Aluminum profile, plastic end caps
- INTERFACE/CONTROL:
- SAFETY OUTPUTS: 2 x OSSD (PNP, short-circuit protected)
- INDICATORS: Multi-color LEDs for alignment, operating status, and error
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65 (IEC 60529)
- OPERATING TEMPERATURE: -30 °C ... +55 °C
- MOUNTING: Standard swivel mounts or fixed brackets (not included)
- COMPATIBILITY/APPLICATION:
- SAFETY INTEGRITY LEVEL: SIL3 (IEC 61508), PL e (ISO 13849-1)
- SAFETY TYPE: Type 4 (IEC 61496-1, IEC 61496-2)
- APPLICATIONS: Machine guarding, access protection, hazardous point protection in automated manufacturing, assembly, and packaging lines.
