SICK 6013296 - Safety Light Curtain
This is a Type 4 electro-sensitive protective equipment (ESPE) from the SICK deTec4 Core series, designed for personnel protection in hazardous industrial environments. It provides reliable finger protection with a 14 mm resolution and a 300 mm protective field height, integrating into safety circuits for applications such as machine guarding, access control, and hazardous point protection in automated manufacturing and assembly processes. The system utilizes OSSD outputs for direct connection to safety controllers or relays, ensuring compliance with international safety standards.
Technical Specifications:
- SERIES/FAMILY: deTec4 Core
- COMPONENT TYPE: Safety Light Curtain (Sender/Receiver Pair)
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24V DC
- VOLTAGE RANGE: 19.2 V DC ... 28.8 V DC
- CURRENT CONSUMPTION: Max. 100 mA (per unit, sender or receiver)
- MECHANICAL/PHYSICAL:
- PROTECTIVE FIELD HEIGHT: 300 mm
- RESOLUTION: 14 mm (Finger Protection)
- HOUSING MATERIAL: Aluminum profile, plastic end caps
- HOUSING CROSS-SECTION: 34 mm x 29 mm
- INTERFACE/CONTROL:
- OUTPUTS: 2 x OSSD (PNP, short-circuit protected)
- INPUTS: EDM (External Device Monitoring), Restart Interlock
- CONNECTION TYPE: M12 male connector, 5-pin
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65
- OPERATING TEMPERATURE: -30 °C ... +55 °C
- MOUNTING STYLE: Swivel mounts or side brackets (accessories required)
- COMPATIBILITY/APPLICATION:
- SAFETY STANDARD: Type 4 (IEC 61496-1), PL e (EN ISO 13849-1), SIL3 (IEC 61508)
- TARGET APPLICATIONS: Machine guarding, access protection, hazardous point protection, robotic cells, presses, automated assembly lines, packaging machinery.
