SICK 6013767 - Safety Light Curtain
The SICK deTec4 Core 30-1500 is a Type 4 electro-sensitive protective equipment (ESPE) designed for hazardous point and access protection in industrial environments. This safety light curtain provides a 30mm resolution protective field over a 1500mm height, ensuring personnel safety in accordance with SIL2/PL d standards. It integrates directly into machine safety circuits via OSSD outputs, suitable for applications requiring robust and reliable presence detection.
Technical Specifications:
- SERIES/FAMILY: deTec4 Core
- COMPONENT TYPE: Safety Light Curtain
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24 VDC
- VOLTAGE RANGE: 19.2 VDC to 28.8 VDC
- CURRENT CONSUMPTION: Sender 30 mA, Receiver 70 mA (typical)
- OUTPUTS: 2 x OSSD (PNP, switching to high)
- MECHANICAL/PHYSICAL:
- PROTECTIVE FIELD HEIGHT: 1500 mm
- RESOLUTION: 30 mm (Finger Protection)
- OPERATING RANGE: 0 m to 10 m
- HOUSING MATERIAL: Aluminum (ALMGSI 0.5)
- FRONT SCREEN MATERIAL: Polymethyl methacrylate (PMMA)
- INTERFACE/CONTROL:
- CONNECTION TYPE: M12 male connector, 5-pin (Sender) M12 male connector, 8-pin (Receiver)
- SAFETY OUTPUTS: 2 x OSSD
- CONTROL INPUTS: Restart Interlock (RES), External Device Monitoring (EDM)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP65, IP67
- OPERATING TEMPERATURE: -30 °C to +55 °C
- STORAGE TEMPERATURE: -30 °C to +70 °C
- COOLING METHOD: Passive
- MOUNTING STYLE: Standard mounting brackets (e.g., FlexFix)
- COMPATIBILITY/APPLICATION:
- SAFETY INTEGRITY LEVEL: SIL2 (IEC 61508), SILCL2 (IEC 62061)
- PERFORMANCE LEVEL: PL d (EN ISO 13849-1)
- CATEGORY: Category 2 (EN ISO 13849-1)
- TYPE: Type 4 (IEC 61496-1)
- TARGET APPLICATIONS: Hazardous point protection, access protection, machine guarding, robotics, assembly lines, material handling systems.
