SCHNEIDER ELECTRIC XCKP2506P16 - Electromechanical Limit Switch
The SCHNEIDER ELECTRIC XCKP2506P16 is a compact electromechanical limit switch from the OsiSense XCKP series, designed for precise position detection in industrial automation applications. This device utilizes a roller plunger actuator and snap-action contacts to provide reliable feedback for machine control, safety interlocks, and sequence operations across various industrial machinery, including conveyor systems, packaging equipment, and material handling systems. Its robust plastic body and high IP rating ensure operational integrity in demanding industrial environments.
Technical Specifications:
- SERIES/FAMILY: OsiSense XCKP
- COMPONENT TYPE: Electromechanical Limit Switch, Compact Plastic Body, Roller Plunger Actuator
- ELECTRICAL SPECS:
- CONTACT CONFIGURATION: 1 NC + 1 NO (Snap Action)
- RATED OPERATIONAL CURRENT (AC-15): 3 A at 240 V (IEC 60947-5-1)
- RATED OPERATIONAL CURRENT (DC-13): 0.27 A at 250 V (IEC 60947-5-1)
- CONVENTIONAL ENCLOSED THERMAL CURRENT (Ith): 10 A
- RATED INSULATION VOLTAGE (Ui): 300 V (IEC 60947-5-1)
- MECHANICAL/PHYSICAL:
- ACTUATOR TYPE: Roller Plunger, Horizontal Approach
- BODY MATERIAL: Plastic
- HEAD TYPE: Plunger
- MECHANICAL DURABILITY: 10,000,000 cycles
- INTERFACE/CONTROL:
- ELECTRICAL CONNECTION: Screw Clamp Terminals
- CABLE ENTRY: 1 x M16 x 1.5 Cable Gland
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP66, IP67, IP68 (IEC 60529)
- PROTECTION CLASS: Class II (IEC 61140)
- MOUNTING STYLE: Body Fixed, 2 Screws
- OPERATING TEMPERATURE: -25 to 70 degrees C
- COMPATIBILITY/APPLICATION: Position sensing in general industrial machinery, material handling systems, packaging lines, access control, and safety circuits requiring robust and compact electromechanical feedback.
