SCHNEIDER ELECTRIC LGYN12515 - Servo Drive
The SCHNEIDER ELECTRIC LGYN12515 is a digital servo drive from the Lexium 15 series, engineered for precise motion control in demanding industrial automation applications. This unit provides high-performance speed, position, and torque control for synchronous servo motors, making it suitable for machine tools, robotics, packaging machinery, and material handling systems requiring dynamic and accurate motion profiles. It integrates advanced control algorithms to ensure optimal motor performance and system responsiveness.
Technical Specifications:
- SERIES/FAMILY: Lexium 15
- COMPONENT TYPE: Digital Servo Drive
- ELECTRICAL SPECS:
- INPUT VOLTAGE: 200-240 VAC
- PHASE: 3-phase (also compatible with single-phase input at reduced power)
- NOMINAL INPUT FREQUENCY: 50/60 Hz
- CONTINUOUS OUTPUT CURRENT: 12.5 A
- PEAK OUTPUT CURRENT: Up to 37.5 A (for 3 seconds)
- NOMINAL POWER OUTPUT: Approximately 5 kW (at 230V, 3-phase)
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Compact Panel Mount
- COOLING METHOD: Forced Air Convection (integrated fan)
- INTERFACE/CONTROL:
- COMMUNICATION PROTOCOL: CANopen (standard), Modbus RTU (via serial port)
- FEEDBACK INTERFACE: Resolver, Incremental Encoder, Absolute Encoder (Hiperface, EnDat, SSI compatible)
- DIGITAL INPUTS: Configurable for control signals (e.g., enable, limit switches)
- DIGITAL OUTPUTS: Configurable for status indication
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (for panel mounting)
- MOUNTING STYLE: Vertical Panel Mount
- OPERATING TEMPERATURE: 0 to 50 degrees Celsius
- COMPATIBILITY/APPLICATION:
- COMPATIBLE MOTORS: SCHNEIDER ELECTRIC Lexium BMH and BSH series synchronous servo motors
- APPLICATIONS: High-precision positioning, velocity control, and torque regulation in industrial machinery, including CNC machines, printing presses, textile machinery, and automated assembly lines.
