SCHNEIDER ELECTRIC XB5AW33B5C0 - Illuminated Pushbutton
This component is an illuminated pushbutton from the SCHNEIDER ELECTRIC Harmony XB5 series, designed for industrial control and signaling applications. It features a spring return mechanism, a green flush cap, and integrated LED illumination, providing visual feedback for operational status. The unit incorporates a 1 normally open (NO) and 1 normally closed (NC) contact block, suitable for direct control circuit integration in machine interfaces, control panels, and process automation systems.
Technical Specifications:
- SERIES/FAMILY: Harmony XB5
- COMPONENT TYPE: Illuminated Pushbutton, Spring Return
- ELECTRICAL SPECS:
- LED SUPPLY VOLTAGE: 24V AC/DC
- CONTACT CONFIGURATION: 1 NO + 1 NC (Normally Open + Normally Closed)
- RATED OPERATIONAL CURRENT: Typically 3A at 240VAC (AC-15), 0.27A at 250VDC (DC-13)
- MECHANICAL/PHYSICAL:
- HEAD TYPE: Flush, Round
- ACTUATOR COLOR: Green
- ILLUMINATION TYPE: LED
- MOUNTING DIAMETER: 22 mm
- MATERIAL: Plastic Bezel
- INTERFACE/CONTROL:
- OPERATION: Momentary (Spring Return)
- TERMINALS: Screw Clamp
- ENVIRONMENTAL/MOUNTING:
- IP RATING (FRONT FACE): IP66, IP67, IP69, IP69K
- IP RATING (REAR CONTACT BLOCK): IP20
- OPERATING TEMPERATURE: -25°C to +70°C
- MOUNTING STYLE: Panel Mount
- COMPATIBILITY/APPLICATION: Industrial control panels, machine operator interfaces, process control systems, automation equipment.
