SCHNEIDER ELECTRIC XB5FG21 - Selector Switch, 2-Position, Spring Return
This is a Harmony XB5 series 22mm plastic selector switch designed for industrial control panels. It provides momentary control for two distinct states, featuring a spring return mechanism from the right position to the center. The unit integrates 2 normally open (NO) and 1 normally closed (NC) contact blocks for direct circuit control in machine operation and safety interlock applications.
Technical Specifications:
- SERIES/FAMILY: Harmony XB5
- COMPONENT TYPE: Selector Switch, 2-Position, Spring Return
- ELECTRICAL SPECS:
- RATED INSULATION VOLTAGE (Ui): 600V (IEC 60947-1)
- RATED IMPULSE WITHSTAND VOLTAGE (Uimp): 6 kV
- RATED OPERATIONAL CURRENT (Ie): 1.2A at 600V AC-15 0.1A at 600V DC-13 (IEC 60947-5-1)
- CONTACT CONFIGURATION: 2 Normally Open (NO), 1 Normally Closed (NC)
- MECHANICAL/PHYSICAL:
- ACTUATOR TYPE: Standard Handle
- ACTUATOR POSITIONS: 2 (Right to Center Spring Return)
- MOUNTING DIAMETER: 22 mm
- MATERIAL: Plastic Bezel, Plastic Actuator
- MECHANICAL DURABILITY: 1,000,000 cycles
- INTERFACE/CONTROL:
- CONNECTION TYPE: Screw Clamp Terminals
- CONTROL FUNCTION: Momentary (from right position)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP66, IP67, IP69, IP69K (front panel)
- NEMA RATING: NEMA 13, NEMA 4X (front panel)
- OPERATING TEMPERATURE: -25 to 70 degrees C
- MOUNTING STYLE: Panel Mount (22mm hole)
- COMPATIBILITY/APPLICATION:
- Industrial Control Panels
- Machine Start/Stop Circuits
- Mode Selection
- Safety Interlocks
- Process Control Systems
