SCHNEIDER ELECTRIC 9001KP7R9 - Pushbutton, Flush, Red
This device is a 30mm metal control and signaling unit from the SCHNEIDER ELECTRIC Harmony 9001K series. It functions as a momentary flush pushbutton, providing manual control input for industrial machinery and process control applications. The unit features a robust chrome-plated metal construction, a red operator, and a standard contact block configuration, ensuring reliable human-machine interface in demanding operational environments.
Technical Specifications:
- SERIES/FAMILY: Harmony 9001K
- COMPONENT TYPE: Pushbutton, Flush Head, Momentary
- ELECTRICAL SPECS:
- CONTACT RATING: 10A (AC-15, A600 DC-13, Q600)
- NOMINAL INSULATION VOLTAGE (Ui): 600V (IEC 60947-1)
- NOMINAL IMPULSE WITHSTAND VOLTAGE (Uimp): 6kV (IEC 60947-1)
- CONTACT CONFIGURATION: 1 Normally Open (NO) + 1 Normally Closed (NC)
- MECHANICAL/PHYSICAL:
- MOUNTING DIAMETER: 30mm
- HEAD TYPE: Flush
- OPERATOR ACTION: Momentary
- COLOR: Red
- MATERIAL: Chrome-plated metal bezel, plastic body
- INTERFACE/CONTROL:
- TERMINALS: Screw clamp terminals
- ACTUATION: Manual push
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP66 (front face per IEC 60529)
- NEMA RATING: NEMA 1, 2, 3, 3R, 4, 6, 12, 13 (per UL 508)
- OPERATING TEMPERATURE: -25°C to +70°C
- MOUNTING STYLE: Panel mount, single hole
- COMPATIBILITY/APPLICATION:
- CONTROL SYSTEMS: Industrial control panels, motor control centers, machine tools, material handling systems, process control.
- APPLICATIONS: Start/stop functions, reset, general machine control, safety interlocks (when integrated into a safety circuit).
